2 Select a lighting fixture.
3 To add the lighting fixture to a light group, do the following:
a On the Options Bar, for Light Group, select the desired group.
If the light group does not yet exist, select Edit/New, and create a group. See
Light Group
b At the prompt, click OK.
4 To remove the lighting fixture from a light group, do the following:
a On the Options Bar, for Light Group, select None.
b At the prompt, click OK.
Adding and Removing Lights in a Light Group Using the Artificial
Lights Dialog
1 Open the Artificial Lights dialog.
See Opening the Artificial Lights Dialog
2 To add an individual lighting fixture to a light group, do the following:
a In the Artificial Lights dialog, under Ungrouped Lights, select the lighting fixture.
b Under Fixture Options, click Move to Group.
c In the Light Groups dialog, select the desired light group, and click OK.
In the Artificial Lights dialog, the selected lighting fixture displays under the selected light group
name.
3 To remove an individual lighting fixture from a light group, do the following:
a In the Artificial Lights dialog, under Grouped Lights, expand the light group name.
b Select the lighting fixture to remove from the group.
c Under Fixture Options, click Remove from Group.
In the Artificial Lights dialog, the selected lighting fixture displays under Ungrouped Lights.
4 When you are finished in the Artificial Lights dialog, click OK.
Adding and Removing Lights in a Light Group Using the Light Group
Editor
1 Open the Light Group Editor, using either of the following methods:
In a project view, select a lighting fixture. On the Options Bar, for Light Group, click Edit.
NOTE If Light Group displays None, select the light group to which you want to add the selected
lighting fixture. Then click Edit.
Open the Artificial Lights
Group Options, click Edit.
on page 1136.
on page 1136.
dialog. In the Artificial Lights dialog, select the group name. Under
Creating a
