Creating a Framing Elevation View

NOTE You must have a grid in your view before you can add a framing elevation view. See
information on drawing a grid.
1 Click View menu
2 Place the framing elevation symbol perpendicular to the selected grid line and in the direction
3 Press ESC to finish.
4 Double-click the callout head to open the framing elevation.
90 | Chapter 4 Project Views
New
of view to display.
The view represents a full-height view of the area at the work plane of the grid or of the reference
plane. The view is constrained to the surrounding grids or limits of the reference plane.
Framing Elevation.
Grids on page 1033 for
