Segmenting a Section View

1 Sketch a section in a view, or select an existing section.
2 On the Options Bar, click Split Segment.
3 Place the cursor on the section line at the point it is to be segmented, and click.
4 Move the cursor to the side of the split to move, and move the cursor in a direction orthogonal
to the view direction.
5 Click to place the section.
Segmented Section View | 95
