5 Under Lighting, specify lighting settings for the rendered image.
6 Under Background, specify a background for the rendered image.
7 (Optional) Adjust exposure settings for the rendered image.
These render settings are view-specific. They are saved as part of the view properties. To apply these settings
to other 3D views, use a view template. See
When you finish defining render settings, create the rendered image. See
page 1168.

Opening the Rendering Dialog

1 Open the 3D view to render.
2 If the Rendering dialog does not open automatically, use any of the following methods:
1160 | Chapter 17 Rendering
inches before displaying the DPI or pixel size.) Select a predefined value, or enter a custom
value.
The Width, Height, and Uncompressed image size fields update to reflect the settings. See
Performance and Image Size/Quality
See Controlling Lighting in a Rendered Image
See Specifying the Background for a Rendered Image
If you know the exposure settings that you want to use, you can set them now. Otherwise, wait
to see the results of the current render settings, and, if needed, adjust the exposure settings after
rendering the image. See
You can render 3D views only.
TIP To render a 2D view, create a 3D view that is oriented to a 2D view (such as a section view or
elevation view). Use View menu
Location in a 3D View on page 113.
If the Rendering dialog was open when the 3D view was last open in the current session, the
dialog redisplays.
Type rr.
On the View Control Bar, click
On the Rendering tab of the Design Bar, click Rendering Dialog.
Click View menu Rendering Dialog.
on page 1175.
on page 1166.
Adjusting the Exposure of a Rendered Image
View Templates for Render Settings
Orient To Other View. For details, see
(Show Rendering Dialog).
on page 1167.
on page 1168.
on page 1171.
Creating the Rendered Image
Specifying Camera
Render
