Decal Properties

You can modify properties for each decal instance and decal type. You can also change attributes of the
decal image.

Modifying Decal Properties

1 In a project view, select the decal, and click
2 In the Element Properties dialog, edit decal instance parameters.
3 To edit decal type parameters, click Edit/New.
4 To change the decal image and its attributes, in the Type Properties dialog, for Decal Attributes,
5 Click OK.

Decal Instance Properties

Parameter
Dimensions
Width
Height
Lock Proportions
Identity Data
Comments
Mark
Subcategory
Phasing
1156 | Chapter 17 Rendering
See Decal Instance Properties
See Decal Type Properties
click Edit.
See Decal Attributes on page 1157.
NOTE You can also change the decal image and its attributes by clicking Settings menu
Types.
Description
Physical width of the decal.
Physical height of the decal.
Whether the ratio between the height and width is maintained. Clear this option
to change the Width or Height without also affecting the other dimension.
Text that describes the decal.
User-specified identifier for this particular decal.
Subcategory for the geometry of the decal. The subcategory controls the line
weight, color, and pattern in 2D and 3D views. Select a Generic Model subcategory
from the list, or create one. See
on page 1156.
on page 1157.
Creating Object Style Subcategories
(Element Properties).
Decal
on page 484.
