Ramp Properties

You can modify several properties for ramps, including thickness, slope, and base level.

Modifying Ramp Properties

1 If you are in sketch mode, click Modify Ramps > Edit Sketch tab
2 In the Instance Properties dialog, edit ramp instance parameters.
3 Click Edit Type to edit ramp type parameters.
4 Click OK.

Ramp Type Properties

Name
Construction
Thickness
Function
Graphics
Text Size
Text Font
Materials and Finishes
Ramp Material
Dimensions
Maximum Incline Length
Identity Data
Keynote
Model
744 | Chapter 13 Architectural Design
Properties. If you are in a plan view, select the ramp, and click Modify Ramps tab
panel Element Properties.
See Ramp Instance Properties
See Ramp Type Properties
NOTE Changes made to type properties affect all ramps of this type in the project. You can click
Duplicate to create a new ramp type.
Description
Sets the thickness of the ramp. This property is enabled only when the Shape
property is set to thick.
Indicates whether a ramp is interior (default value) or exterior. Function is used in
scheduling and to create filters that simplify a model when exporting.
The size of the font for the ramp's up text and down text.
The font for the ramp's up text and down text.
Material applied to the surface of the ramp for rendering.
Specifies the maximum amount of consecutive rise in a ramp before a landing is
required.
Add or edit the ramp keynote. Click in the value box to open the Keynotes dialog.
See
Defines the ramp model.
on page 745.
on page 744.
Keynotes on page 1117.
Element panel Ramp
Element
