2-6-8. Mains Distribution Board 200PL1 Test Points
Test Point
PT1
PT2
PT3
PT4
PT5
PT6
PT7
PT8
PT9
PT10
PT11
PT12
PT13
PT14
PT15
PT16
PT17
PT18
PT19
PT20
0VE
Indicators and Switches.fm
Service Information and Procedures Class A 2385072-16-8EN
Label (in French)
+12 V (+VR)
0VV
+12 V (+VV)
E_Sup_Emax
E_Sup_EPRE
E_Sup_30V
E_Sup_Emin
+VE
-VE
Ref 400 V
Ref 250 V
0 V (0 VE)
MES_E_B (0 V)
-8 V (-VE)
+8 V (+VE)
Ref 30 V
+5 V
MES_E_a (600 V)
Ref 700 V
B2 Output
0 VE
Page no. 269
Function (in English)
+12 V Permanent
0V
+12 V Premanent
Info DC Bus > 700 V
Info DC Bus > 250 V
Info DC Bus > 30 V
Info DC Bus > 400 V
+VE (+8 V)
-VE (-8 V)
Reference 400 V (Min threshold)
Reference 250 V (Precharge)
0 V
DC Bus Measure 1
-8 V (internal for 200PL1)
+8 V (internal for 200PL1)
Reference 30 V (DC Bus Detection)
+5 V
DC Bus Measure 2
Reference 700 V (Max threshold)
DC Bus Measure Voltage
0 V
