GE Healthcare
Revision 1
DS12
Security Re-obtainable
DS13
Security Blocked
2-3-4.
Generator Command Board 400PL1 Jumpers
Jumper
1. Check that jumpers JP1 and JP2 are installed on Generator Command Board 400PL1. They must
not be installed in the parking position JP3 and JP4 at this point. See illustration below.
Note:
JP1 and JP2 are connected to the room relays on Generator Command Board 200PL4. Refer to
Job Card PHY A018 - Room Lamps and Door Configuration on page 475
•
Board-Generator Command 400PL1; see component index page 179
Indicators and Switches.fm
JP1
Defines lamp behavior when the door is open/closed
JP2
Defines lamp behavior when the door is open/closed
JP3
Parking for unused jumpers in JP1 (see text below)
JP4
Parking for unused jumpers in JP2 (see text below)
JP3 & JP4
(parking)
XJ8
XJ13
JP2
Service Information and Procedures Class A 2385072-16-8EN
Red
Normal status: OFF
ON when the security signal has been triggered by
kV max, Chute kV, mA max, or Iond max.
OFF when there is no security issue.
Red
Normal status: OFF
ON when the security signal has been triggered by
DEF alim or DEF TRAD.
OFF when there is no security issue.
Function
XJ
10
JP1
Page no. 255
Senographe DS
for more information.
.
Right bottom edge
of board
Central Listing
Chapter 3
