GE Senographe DS Manual page 235

GE Healthcare
Revision 1
Name/photo
Male Loopback - COM
Male Loopback - RT
Female Loopback - COM
Female Loopback - RT
Adapter-Loopback Sub D 9F/25Mr
FO Loopback Connector - SC
Wall Connector (2x optical fiber)
Wall Connector Optical Fiber
FO Loopback Connector - LC
Tool-Glossary.fm
Service Information and Procedures Class A 2385072-16-8EN
PN Used
Elsewhere
5342936 N
5342937 N
5342935 N
5315956 N
2198175-2 N
5260771 N
2231528 N
2255935 N
5260765 N
Page no. 235
Function
9 pin male loopback adapter, which
can be used to perform loopback tests
with the (serial) COM line between the
IDC and Generator
9 pin male loopback adapter, which
can be used to perform loopback tests
with the RT line between the IDC and
Generator
9 pin female loopback adapter, which
can be used to perform loopback tests
with the (serial) COM line between the
IDC and Generator
9 pin female loopback adapter, which
can be used to perform loopback tests
with the RT line between the IDC and
Generator
9-pin to 25-pin adapter.
Optical fiber loopback cable with SC-
type optical connectors.
Optical fiber loopback cable.
Senographe DS
Tools Glossary
Chapter 3
