GE Senographe DS Manual page 268

GE Healthcare
Revision 1
Central Listing
2-6-3. Mains Distribution Board 200PL1 Neon Lights
LED
N1 Power Present
N2 K1 under tension
2-6-4. Mains Distribution Board 200PL1 Fuses
Fuse
F1
F2
F3
2-6-5. Mains Distribution Board 200PL1 Potentiometers
Strap
2-6-6. Mains Distribution Board 200PL1 Straps
Strap
2-6-7. Mains Distribution Board 200PL1 Switches
Chapter 3
Function
Specification
250 Vac, 1 A, Delay
250 Vac, 0.5 A, Delay
P1
P2
IN1
IN2 BT Power Selector. Must be on left-hand side in the BT position.
Strap
SW1
SW2
Service Information and Procedures Class A 2385072-16-8EN
Color
Orange Normal status: ON
ON when power from the Generator Transformer is
present.
OFF when power from the Generator Transformer
is not present. In this case check the status of the
N2 neon light.
Orange Normal status: ON
ON when the K1 contact is under tension.
OFF when the K1 contact is not under tension. In
this case, proceed as follows:
• Check the X2 relay on the Mains Distribution
Board 200PL1.
• If the X2 relay is okay, check that the tension
selector (SEL) is on the correct value.
• If the X2 relay and the tension selector are OK,
check the upstream fuses at the mains input.
PN
58079686
58079685
Function
Threshold E_Sup_EMax_a
Threshold E_Sup_EMin_a
Function
Not Applicable
Function
Test measure E
Test measure E
Page no. 268
Senographe DS
Behavior
Function
1 A/250 V (+8 V)
0.5 A/250 V (-8 V)
0.5 A/250 V (+12 V)
Indicators and Switches.fm
