2-4-1.
Inverter Board 300PL1 Connectors
Connector
XJ1
To the XJ7 connector on the Generator Command Board 400PL1 (Prep, Exposure thyristor
X1
X2
X3
X4
X5
X6
X7
X8
X9
X10
X11
X12
X13
X14
X15
X16
Indicators and Switches.fm
Service Information and Procedures Class A 2385072-16-8EN
Function
command)
0V/600VR
Not Applicable
415 V Monophase (1)
415 V Monophase (2)
600VR
300VR
600VF
HF2
HF1
0V/600VF
Thermal Switch (1)
Thermal Switch (2)
Gate/TH1
K / TH1
Gate/TH2
K / TH2
Page no. 259
