GE Healthcare
Revision 1
Central Listing
2-4-2.
Inverter Board 300PL1 Neon Lights
LED
L1
2-4-3.
Inverter Board 300PL1 Straps
2-4-4.
Inverter Board 300PL1 Test Points
Test Point
PT1
PT2
PT3
PT4
PT5
Chapter 3
Function
600 V Present
Strap
ST1
ST2
Label (in French)
A/TH1
HF1
K/TH2
600VF
0V/600VF
Service Information and Procedures Class A 2385072-16-8EN
Color
Clear
Normal status: ON
ON when the 600 V from the Mains Distribution
Board 200PL1 is present.
OFF when there is a problem with the 600 V from
the Mains Distribution Board 200PL1. In this case,
proceed as follows:
Check the states of the all the LEDs on the Mains
Distribution Board 200PL1(see
Board 200PL1 LEDs on page
• If the states of any of the LEDs are abnormal, fix
the problem as described in
Board 200PL1 LEDs on page
• If the states of all the LEDs are normal, check with
a multimeter that the voltage between the X3 and
X4 connectors on the Inverter Board 300PL1 is at
415 V.
If the voltage is at 415 V, change the Inverter
Board 300PL1.
If the voltage is not at 415 V, check the cabling
between the Mains Distribution Board 200PL1
and the capacitors of the DC Bus on the Inverter
Board 300PL1.
Function
Gate TH1
Gate TH2
Page no. 260
Behavior
Mains Distribution
264).
Mains Distribution
264.
Function (in English)
600 VF supply at 0 V
Senographe DS
Indicators and Switches.fm
- Quick Links:
- Err Sub A001 - Generator Error...
Hide quick links:
Advertisement
Table of Contents
Troubleshooting
Need help?
Do you have a question about the Senographe DS and is the answer not in the manual?
Questions and answers
G.E.Essential l have recently bought What is the full weight.of the mamo Full weight of the console and other İtem's also measurements of each item with the main machine please All this Shipping Company required
The GE Senographe DS mammography machine is shipped in three crates with the following dimensions and weights:
- Crate 1 (Gantry, Generator Cabinet, and ramp):
- Dimensions: 2066 mm (81.34 in) depth × 848 mm (33.39 in) width × 2292 mm (90.24 in) height
- Mass: 641 kg (1410.2 lbs)
- Crate 2 (Control Station):
- Dimensions: 1110 mm (43.70 in) depth × 770 mm (30.31 in) width × 1850 mm (72.83 in) height
- Mass: 210.5 kg (464.07 lbs) for truck transport (without side covers and lid)
- Mass: 223.5 kg (492.73 lbs) for plane/boat transport (with side covers and lid)
- Crate 3 (Detector):
- Dimensions: 872 mm (34.33 in) depth × 2270 mm (89.37 in) width × 260 mm (10.24 in) height
- Mass: 104.4 kg (229.68 lbs)
### Total Mass:
- For truck transport: 641 + 210.5 + 104.4 = 955.9 kg (2104.95 lbs)
- For plane/boat transport: 641 + 223.5 + 104.4 = 968.9 kg (2133.61 lbs)
These values include the gantry, generator cabinet, control station, detector, and all related components.
