Linked Model Properties

You can modify the properties of a linked model, including the name of the linked model instance and the
shared positioning settings.
To modify linked model properties, right-click the linked model name in the Project Browser (under Revit
Links), and click Properties. Alternatively, you can select the linked model in the drawing area, and click
.
You can also view the properties of an element contained in a linked Revit model. All properties for elements
in linked models are read-only.
To view element properties in a linked Revit model:
1 Hover the cursor over the element in the linked file and press TAB to highlight the element.
2 Click the element and click
Linked Model Type Properties
Name
Room Bounding
Reference Type
Phase Mapping
Linked Model Instance Properties
Name
Name
Shared Location

Managing Links

After creating a link to a CAD format, DWF markup, or Revit model, you have several options for controlling
those links.
1222 | Chapter 19 Working with Linked Models
.
Description
Makes the host project recognize the Room Bounding parameter of elements in the linked
model. See Room Boundaries in Linked Models
Determines whether nested linked models are shown (Attachment) or hidden (Overlay).
See Showing or Hiding Nested Linked Revit Models
Allows you to set up the phase map for the linked model. See
Revit Models on page 1216.
Description
Specifies the name of the linked model instance. Names are automatically generated
when you make a copy of a linked model in the project. You can change the name.
Names must be unique; a message appears if you enter a name that already exists in the
project. Names of linked models are useful when you have multiple copies of the same
linked model in a project and need to add the linked model elements to a schedule. See
Including Elements from Linked Models in a Schedule
Specifies the shared coordinates for the linked model. See
1230.
on page 920.
on page 1215.
Phase Mapping Linked
on page 129.
Shared Positioning on page
