Design Options Toolbar

Before working with design options, display the Design Options toolbar. This toolbar offers one-click access
to the functions available using Tools menu
To display the Design Options toolbar
Do either of the following:
Click Window menu
Move the cursor over any part of the toolbar area in the Revit window, right-click, and click Design
Options.
By default, the Design Options toolbar is located on the right side of the Revit window, in the second row
of toolbar buttons. You can drag the toolbar handle to move it to a different location in the toolbar area.
Use the buttons of the Design Options toolbar as follows:
Button

Design Options Terminology

Term
Main model
Design option set
Design option
1240 | Chapter 20 Design Options
Toolbar Design Options.
Tooltip
Design Options
Add to Design Option Set
Choose a Design Option to
Edit, or Editing: '<design
option set> : <design op-
tion>'
Description
The parts of the building model that are not defined using design options. The main model is the
entire building model, excluding any design options.
A collection of alternatives that addresses a particular design problem, such as a lobby or a floor
layout. See Creating Design Option Sets
One possible solution to the design problem. See
with Design Options
Design Options.
Description
Opens the Design Options dialog, from which you can manage design options
and option sets. This button corresponds to Tools menu
tions Design Options.
Moves an element from the main model to one or more design options in a
set. This button corresponds to Tools menu
Design Option Set.
Displays a menu of options, which allow you to select a design option for
editing, or to indicate that you are finished editing the active option. This
button corresponds to Tools menu
functions of the Design Options dialog. When you are editing an option, this
button appears selected, and the tooltip indicates the active option.
on page 1242.
Adding Design Options
on page 1244.
Design Op-
Design Options Add to
Design Options Pick to Edit, and
on page 1243 and Working
