Universal Serial Bus Interface
• Rule 3: If transitioning from Do_Start Split to Do Complete Split and the current value of
FRINDEX[2–0] is not 6, or currently in Do Complete Split and the current value of
(FRINDEX[2–0]) is not 7, FrameTag is set to FRINDEX[7–3]. This accommodates all other cases
in Figure 16-53.

16.6.12.2.9 Rebalancing the Periodic Schedule

System software must occasionally adjust a periodic queue head's S-mask and C-mask fields during
operation. This need occurs when adjustments to the periodic schedule create a new bandwidth budget and
one or more queue head's are assigned new execution footprints (that is, new S-mask and C-mask values).
It is imperative that system software must not update these masks to new values in the midst of a split
transaction. In order to avoid any race conditions with the update, the host controller provides a simple
assist to system software. System software sets the Inactivate-on-next-Transaction (I) bit to signal the host
controller that it intends to update the S-mask and C-mask on this queue head. System software then waits
for the host controller to observe the I-bit is set and transitions the Active bit to a zero. The rules for how
and when the host controller clears the Active bit are:
• If the Active bit is cleared, no action is taken. The host controller does not attempt to advance the
queue when the I-bit is set.
• If the Active bit is set and the SplitXState is DoStart (regardless of the value of S-mask), the host
controller simply clears the Active bit. The host controller is not required to write the transfer state
back to the current qTD. Note that if the S-mask indicates that a start-split is scheduled for the
current microframe, the host controller must not issue the start-split bus transaction; it must clear
the Active bit.
System software must save transfer state before setting the I-bit. This is required so that it can correctly
determine what transfer progress (if any) occurred after the I-bit was set and the host controller executed
it's final bus-transaction and cleared the Active bit.
After system software has updated the S-mask and C-mask, it must then reactivate the queue head. Since
the Active bit and the I-bit cannot be updated with the same write, system software needs to use the
following algorithm to coherently re-activate a queue head that has been stopped using the I-bit.
1. Set the Halted bit, then
2. Clear the I-bit, then
3. Set the Active bit and clear the Halted bit in the same write.
Setting the Halted bit inhibits the host controller from attempting to advance the queue between the time
the I-bit is cleared and the Active bit is set.

16.6.12.3 Split Transaction Isochronous

Full-speed isochronous transfers are managed using the split-transaction protocol through a USB 2.0
transaction translator in a USB 2.0 hub. The host controller utilizes siTD data structure to support the
special requirements of isochronous split-transactions. This data structure uses the scheduling model of
isochronous TDs (see Section 16.6.8, "Managing Isochronous Transfers Using iTDs,"
model of iTDs) with the contiguous data feature provided by queue heads. This simple arrangement allows
MPC8313E PowerQUICC II Pro Integrated Processor Family Reference Manual, Rev. 3
16-106
for the operational
Freescale Semiconductor
