Changing the Structure of Infill Elements

If you demolish an insert in a phase later than the host's creation phase, you can change the structure of
the infill element. You can use this technique to represent different materials and thicknesses in the host.
NOTE You cannot change the structure of an infill element created for phases earlier than the insert's phase.
To change the structure of an infill element
1 Open a section view that passes through the demolished insert.
2 Right-click in the view, and click View Properties.
3 In the Element Properties dialog, for Phase Filter, select Show Previous + New.
4 Click OK.
5 Select the infill element in the view.
6 From the Type Selector, select the desired host element type.
The infill element updates accordingly, as shown in the following section view.
This filter shows all original elements that were not demolished and all new elements added to
the building model.
You may need to move the cursor along a face of the element until it highlights. (Watch the
status bar for information about highlighted elements.) The following image shows a selected
infill element.
Changing the Structure of Infill Elements | 1269
