area report. These reports contain information about all rooms or areas with floors on the corresponding
level. Each report is generated as an HTML file.
When creating a room/area report, you can choose from the following formats:
Revit room area triangulation report. For each room or area in the selected plan, the report contains
images of room boundaries or area boundaries, which are triangulated and annotated. Following each
image, a table shows calculations for the triangulated areas, as well as total room area and total window
area.
Revit room area numerical integration report. For each room or area in the selected plan, the report
contains a table that lists segments, sub-areas, and their dimensions. Each table is followed by the total
room area and total window area.
You can create triangulation reports that exclude areas bounded by multiple curve loops (such as a room
with columns or closets in the middle). When a room/area report excludes these areas, triangulation is
performed, reported, and displayed separately for each bounding loop. (This option only applies to Revit
room area triangulation reports; it is ignored for Revit room area numerical integration reports.)
This functionality is primarily intended for the European market.

Exporting a View as a Room/Area Report

1 Click File menu
The Export Room Area Report dialog displays.
2 For Files of Type, select the type of report to create: triangulation or numerical integration.
3 If you are exporting a single view, do the following:
a Under Range, select Current View.
b If the current view is a floor plan or an area plan, the File Name text box displays a default
file name. If desired, change the file name, and navigate to a target folder.
4 If you are exporting multiple views, do the following:
a Under Range, click Select Views.
b In the Views dialog, select the views to export, and click OK.
c For File Name, enter a prefix for the names of the exported files.
5 Click Options.
6 In the Area Report Settings dialog, do the following:
a If desired, change settings for text format, label prefixes for triangles and arc sectors, line
colors, unit format, and image sizes.
b For a triangulation report, select Use Triangulation with Exclusions if you want to exclude
areas bounded by multiple curve loops. (This setting has no effect for numerical integration
reports.)
c To report window area as a percentage of total area, select Report Window Area as a
Percentage of Room Area. By default, the report calculates the total window area.
d Click OK.
7 Click Save.
Export Room/Area Report.
Creating Room/Area Reports | 1291
