5 Repeat Steps 2–4 for each combination of design options that you want to show in individual
For each dedicated view, you can now do the following:
Modify the view, for example, to add annotations and details for design options. See
Detailing
Modify a design option. See
Place the view on a sheet to share the design options with clients. See
Related topics
View Tags in Dedicated Views for Design Options
Deleting Views Associated with Design Options

Viewing the Main Model Without Design Options

If you want to be able to view the main model only, with no design options, create an empty design option
and make it the primary option. (See
option sets, create an empty option for each set, and make it the primary option for each set.
By default, all project views will then display the main model only. To display other design options, see
Viewing Design Options

Viewing Multiple Design Options

A project view can display only one design option for each set. To view and compare design options
side-by-side, dedicate a view to each design option. (See
Then place the views on a sheet. (See

Checking the Design Option Settings for a View

1 Open a project view in which you want to see or edit a design option.
2 On the keyboard, type VG (for Visibility/Graphics).
3 On the Visibility/Graphics dialog, click the Design Options tab.
The Visibility dialog displays the Design Options tab. It lists each design option set, and,
for each set, the design option that the view is currently displaying.
A value of Automatic indicates the following:
When no design option is being edited, the view displays the primary option.
When a design option is being edited, the view displays the active option.
c For each design option set, select the design option to display in this view.
If you have created multiple design option sets, the view displays one option for each set.
d Click OK.
The view displays the main model and a selected design option for each set.
views.
on page 1027.
Editing a Design Option
on page 1252.
on page 1244.
on page 1254
on page 1251
Adding Design Options on page 1243.) If you are using multiple design
Dedicating Views to Design Options
Adding Views to a Sheet
Viewing the Main Model Without Design Options | 1253
Sheets on page 968.
on page 971.)
Annotating and
on page 1252.)
