4 Under Image Size, specify image display properties, as follows:
5 Under Options, select the desired print options:
6 Under Format, select an output format for shaded views and non-shaded views. If you specified
7 Click OK.
The selected sheets or views are exported as images in the specified file.
Exporting Project Views to HTML
You can create a web page that links HTML versions of views and sheets in a Revit Architecture project.
To export project views to HTML
1 Click File menu
2 In the Export Image dialog, under Export Range, select Selected Views/Sheets.
3 Click Select.
4 In the View/Sheet Set dialog, select the views and sheets to export, and click OK.
5 Under Output, do the following:
6 Specify Image Size, Options, and Format settings as desired.
7 Click OK.
Revit Architecture creates a web page. From the web page, you can open the views from a table of contents.
View tags are hyperlinks. For example, suppose you export the Level 1 view and the North Elevation view.
In the web page, when viewing the North Elevation view, you can click the Level view tag to link to the
Level 1 view.
In the folder where the web page resides, Revit Architecture creates a folder containing the source HTML
files and images. The folder also contains a cascading style sheet (CSS file). Edit this file to change the format
of the web page.
Creating Room/Area Reports
You can create a detailed report that describes areas defined in plan views (floor plans and area plans). For
a floor plan, Revit Architecture generates a room report. For an area plan, Revit Architecture generates an
1290 | Chapter 22 Interoperability
To specify a print size and orientation for the image, select Fit To and enter a pixel value.
For Direction, select Horizontal or Vertical. Revit Architecture fits the image horizontally or
vertically into the specified number of pixels.
To magnify or reduce the image, select Zoom To and enter a percentage. Revit Architecture
prints the image at the specified zoom setting.
By default, links in the exported image display in black. To display blue links, select View
Links in Blue.
To hide unwanted parts of the drawing in the exported view, select any of the following:
Hide Ref/Work Planes, Hide Scope Boxes, Hide Crop Boundaries, and Hide Unreferenced
View Tags.
a Zoom To percentage for Image Size, select a DPI (dots per inch) value for Raster Image Quality.
Export
For Name, specify the desired path and a prefix for resulting file names.
Select Create Browsable Web Site with a Linked HTML Page for Each View.
For details about these settings, see
Image.
Exporting a View to an Image File
on page 1289.
