Structural Wall Instance Properties - Autodesk 256B1-05A761-1301 - AutoCAD Revit Structure Suite 2010 User Manual

Name
Additional Top/Exterior Offset
Additional Bottom/Interior Offset
Additional Offset
Graphics
Coarse Scale Fill Pattern
Coarse Scale Fill Color
Identity Data
Keynote
Model
Manufacturer
Type Comments
URL
Description
Assembly Description
Assembly Code
Type Mark
Fire Rating
Cost

Structural Wall Instance Properties

Name
Constraints
Description
Specifies an additional offset from the top/exterior rebar cover. This allows placing
multiple rebar elements together in different area reinforcement layers.
Specifies an additional offset from the bottom/interior rebar cover. This allows placing
multiple rebar elements together in different area reinforcement layers.
Specifies an additional offset from the rebar cover. This allows placing multiple rebar
elements together in different path reinforcement layers.
Specifies a fill pattern for a wall in a coarse-scale view. See
259.
Specifies a color for the fill pattern for a wall in a coarse-scale view.
Specifies or modifies the structural wall keynote. Click in the value box to open the
Keynotes dialog. See Keynotes
The manufacturer internal number.
The wall manufacturer.
A field for entering general comments about the wall type. This information can be
included in a schedule.
A link to a web page that may contain type-specific information.
A description of the wall.
A description of the assembly based on the assembly code selection. This is a read-
only value.
A uniformat assembly code selected from a hierarchical list.
A value that designates the particular wall. This value must be unique for each ele-
ment in a project. Revit Architecture warns you when the number is already used,
but allows you to continue using it. You can see the warning using the Review
Warnings tool. See Reviewing Warning Messages
The fire rating of the wall.
The pricing of the wall.
Description
View Properties
on page 1117.
on page 1415.
Structural Wall Properties | 913
on page
