Deleting Raster Images

The Raster Images command lists all raster images in the project, including any rendered images that you
have captured. The command offers the only way for you to delete an image from the project. You cannot
remove an image from the project by deleting it from a view or a sheet.
To delete a raster image
1 Click File menu
2 Select the image name, and click Delete.
3 Click OK when prompted to confirm the deletion.
4 Click OK to close the Raster Images dialog.

Importing Industry Foundation Class (IFC) Files

Revit Architecture provides Industry Foundation Classes (IFC) import based on the latest International
Alliance for Interoperability (IAI) IFC 2x3 data exchange standard. (If you import a file that uses an earlier
standard [IFC 2x or 2x2], Revit Architecture supports the format and imports it properly.) For information
about the IFC file format, see
When you import an IFC file, Revit Architecture creates a new file based on the default template. For
information about selecting the default template, see
1317.
You can load your own IFC class mapping files and override the categories and subcategories for imported
IFC objects.
TIP Make sure you import the geometric data needed for the Revit Architecture capability that you plan to use.
For more information, see
To import an IFC file
1 Click File menu
2 In the Import/Link dialog, navigate to the IFC file to import.
3 Select the IFC file, and click Open.
Revit Architecture creates a new file based on the default template.

Selecting a Template for Imported IFC Files

1 Click File menu
2 Click Browse.
3 In the Browse for Template File dialog, navigate to the desired IFC template file, select it, and
4 In the Import IFC Options dialog, click OK.

Loading an IFC Class Mapping File

1 Click File menu
Raster Images.
The Raster Images dialog lists all raster images in the project.
Exporting to Industry Foundation Classes (IFC)
Suitability of Imported Geometry
Import/Link
Import/Export Settings
click Open.
Import/Export Settings
Selecting a Template for Imported IFC Files
on page 1306.
IFC.
IFC Options
IFC Options
Importing Industry Foundation Class (IFC) Files | 1317
on page 1292.
Import Options.
Import Options.
on page
