6 If you want to prohibit Revit Architecture from creating external references (xrefs), select Export
7 To specify export options, click Options, select the desired options, and click OK.
8 In the Export dialog, click Save.
Revit Architecture exports the selected views and sheets to DWG files and places them in the target folder.
When you export a 2D view to a DWG file, lines are treated as follows:
If 2 lines overlap in the drawing, the thicker of the lines is retained. The thinner line is shortened or
removed.
If a thick line is shorter than a thin line and its start point and endpoint fall within the thin line, no
action occurs.
If 2 collinear lines with the same visual parameters overlap, they are merged into one.
When walls become lines in the DWG file, no short collinear lines are produced.

Exporting to DXF

1 Click File menu
2 In the Export dialog, for Save In, navigate to the target folder for the exported files.
3 For Files of Type, select a DXF file format.
4 If you are exporting a single view, do the following:
5 If you are exporting multiple views or sheets, do the following:
6 To specify export options, click Options, select the desired options, and click OK.
7 In the Export dialog, click Save.
Revit Architecture exports the selected views and sheets to DXF files and places them in the target folder.
1276 | Chapter 22 Interoperability
Each View or Sheet as a Single File. Any Revit or DWG links in the project are exported to a
single file rather than several files that reference each other.
For DWG files, you can specify the following options: Layer Settings, Layers and Properties,
Linetype Scaling, Coordinate System Basis, One DWG Unit Is, Solids (3D Views Only), and
Export Rooms and Areas as Polylines. See
Export
a Under Naming, select Manual (Specify file name), or select Automatic - Long (Specify prefix)
or Automatic - Short to use an automatically generated file name. See
Files on page 1278.
b Under Range, select Current View.
a Under Range, select Selected Views/Sheets.
b Click .
c In the View/Sheet Set dialog, select the views or sheets to export, and click OK.
d Under Naming, select Automatic - Short to use a short prefix for the names of the exported
files, or select Automatic - Long (Specify prefix) to use a longer prefix. See
Exported Files on page 1278.
For DXF files, you can specify the following options: Layer Settings, Layers and Properties,
Linetype Scaling, Coordinate System Basis, One DWG Unit Is, Solids (3D Views Only), and
Export Rooms and Areas as Polylines. See
Export Options
CAD Formats.
Export Options
on page 1278.
File Names for Exported
File Names for
on page 1278.
