panel is simple, create an appropriate
panel type derived from the system
panel family. If not, try making the panel
in the wall or roof rectangular, and then
using a panel family of the desired (non-
rectangular) shape. The wall will then
conform to the non-rectangular shape
of the panel.
Cannot divide curtain grid by grid line.
Currently, only straight walls with
straight or arc edges are supported for
non-rectangular curtain walls.
Copy and Paste
Informational Message
Cannot paste selection in [name] view.
Elements were deleted. Use Edit Pasted
Elements to keep them.
Roofs
Informational Message
Can't create Curtain Panel. A Panel or a
Mullion is probably too small.
1336 | Chapter 23 Print Troubleshooting, Diagnostic Tools, and Error Handling
Solution: This problem might occur if a curtain wall with non-system panels joins
to a roof and the curtain wall does not have a rectangular shape. It would also
occur if you create a non-rectangular wall profile and then change that wall to a
curtain wall with non-system panels.
Problem: If you place a curtain grid on a sloped glazing, such that the curtain
grid division results in a complex piece of geometry that Revit Architecture cannot
produce, this error occurs.
Solution: There is no workaround. You have to cancel the action.
Problem: A curtain wall contains an ellipse in one of its sides. This problem could
happen if the wall joins to a roof with an ellipse.
Solution: Cancel the command; this type of curtain wall is not supported.
Details
Problem: Revit Architecture is unable to paste the selected component in the
view.
Solution: If you tried to paste a wall in an elevation view or a section view, you
see this message. Try pasting in a plan, reflected ceiling plan, or 3D view. This
message would also appear if you try to paste a group of components that cannot
be pasted into a certain view: for example, a column group into an elevation
view.
Problem: Revit Architecture requires a proper host for the copied element (for
example, a window needs a wall, a tag or dimension needs reference elements).
Solution: If you tried to paste an element into a location that does not contain
a proper host, you will see this message. Click Cancel to remove the warning. On
the Options Bar, click the Edit Pasted Elements button. In the Edit Pasted mode,
place the copied element onto its proper host. Click Finish Paste to complete the
paste process.
TIP Paste Aligned and Copy commands do not provide the Edit Pasted Elements
button. If you get this message in Paste Aligned or Copy command, you can
cancel and perform the Paste from Clipboard command instead.
Also see Editing Pasted Elements
Details
Problem: Typically, this problem occurs in a panel on a sloped glazing. A hori-
zontal and vertical curtain grid on a panel are not meeting exactly at a point,
creating a small triangular panel within the main panel; the triangular panel
cannot be accurately regenerated because it is too small. This error can result
on page 322.
