Exporting to an ODBC Database

The first time that you export a Revit Architecture project to an ODBC database, use the following procedure.
If you have already exported the project and want to re-export it, see
ODBC Database
To export to an ODBC database
1 In Revit Architecture, open the project to export.
2 Click File menu
3 Click New to create a new Data Source Name (DSN).
4 In the Create New Data Source dialog, do the following:
5 Create the database file.
6 In the Select Data Source dialog, click OK.
7 In the ODBC Setup dialog, click OK.
NOTE If the export fails with an error regarding a read-only database, click Options in the ODBC Microsoft Setup
dialog. Clear the Read Only check box. Then try the export again.

Exporting Multiple Times to the Same ODBC Database

1 In Revit Architecture, open the project to export.
2 Click File menu
3 In the Select Data Source dialog, select the desired data source, and click OK.
4 In the ODBC Setup dialog, click OK to export to the same database.

Editing the Database After Export

Do not edit data in the database columns exported by Revit Architecture. Any changes to those columns
are overwritten the next time the project is exported.
However, you can add columns to the tables created by Revit Architecture. The next time the project is
exported, any data in the added columns is preserved.
1288 | Chapter 22 Interoperability
on page 1288.
Export
a Select a driver and click Next.
This driver is associated with the software program you export to (for example, Microsoft
Access, dBase, or Paradox).
b Enter a DSN name, or navigate to the target folder and specify a file name. Click Next.
c A confirmation dialog displays. If any information is incorrect, click Back and correct it.
d Click Finish.
Depending on the driver selected, a dialog displays, requesting information about the database
file to export to. Use the dialog to specify the database to use or to create a new one. For example:
®
For Microsoft Access, click Select to select an existing database, or click Create to create a
new, empty database to export data to.
®
For Microsoft Excel, first use Excel to create a new, empty workbook with the desired name.
Then on the dialog, click Select Workbook, and navigate to the new workbook.
Export
ODBC Database.
ODBC Database.
Exporting Multiple Times to the Same
®
