5 If you are exporting multiple views and sheets, do the following:
6 To specify a layer mapping file, click Options, click Layer Settings, and specify the file.
7 In the Export dialog, click Save.
Revit Architecture exports the selected views and sheets to SAT files and places them in the target folder.

File Names for Exported Files

When exporting to a CAD
Export dialog, click File menu
options to name the exported files, as follows:
Manual. (For exporting the current view only. This option is not available when exporting multiple
views.) Enter a name for the exported file. Revit Architecture automatically combines any Revit or DWG
links during export, and so always creates a single file.
Automatic. This option adds a prefix to the file name of the current view or multiple views and sheets.
Select one of the following options:
Short. Revit Architecture determines the name automatically. The format is:
Revit Sheet: Sheet Name or Revit View: View Type-View Name
Long. Specify a prefix or accept the default, which uses the format:
Revit Sheet/View: Project Name-View Type-View Name
When exporting multiple files, for File Name, enter a common prefix for the exported files. For example, if
you are exporting the Level 1 floor plan and north elevation views to DWG files and you enter the prefix
Country House, the resulting exported file names are Country House Elevation North.dwg and Country
House Floor Plan Level 1.dwg.

Export Options

When exporting to a CAD format, you can use the Export Options dialog to specify various options. To
access the Export Options dialog, click File menu
Options.
1278 | Chapter 22 Interoperability
a Under Range, select Selected Views/Sheets.
b Click .
c In the View/Sheet Set dialog, select the views and sheets to export and click OK.
d Under Naming, select Automatic - Short to use a short prefix for the names of the exported
files, or select Automatic - Long (Specify prefix) to use a longer prefix. See
Exported Files on page 1278.
For more information, see
NOTE When you export (to SAT format) a 3D view that contains solid geometry, the geometry always
exports as ACIS solids.
format, you can specify a name or prefix for the exported files. To access the
Export
Exporting Layers on page 1285.
CAD Formats. In the Export dialog, under File Naming, use the
Export CAD Formats. On the Export dialog, click
File Names for
