To promote a secondary option to be the primary option
1 Click Tools menu
2 In the Design Options dialog, select the secondary design option to promote.
3 Under Option, click Make Primary.
4 Click Close.
5 In project views that display the main model with the new primary option, check dimension

Moving Elements from the Main Model to a Design Option Set

The main model consists of the entire building model, excluding elements in any design options.
Elements in the main model cannot host or reference elements in secondary options. Therefore, elements
in the main model do not change their shape or properties when you are looking at a view for a secondary
option. For example:
If you sketch 4 walls in the main model and then sketch a roof in a secondary option, you cannot attach
the walls to the roof.
To add a door or window to a design option, the host wall must also be part of the design option.
To add a skylight to a design option, the host roof must also be part of the design option.
If main model elements need to reference and update with elements in a secondary option, you must move
the main model elements into that design option. Then you can edit the design option to modify those
elements as desired. (See
To move elements from the main model to a design option set
1 Display the Design Options toolbar.
2 Open a project view that shows the elements to be moved.
3 Verify that you are not in Design Option Edit mode.
4 Select the main model elements to move.
5 On the Design Options toolbar, click
6 In the Add to Design Option Set dialog, for Add selection to, select the desired set.
7 Select one or more design options to which you want to add the elements.
1246 | Chapter 20 Design Options
Design Options
toolbar.
Revit Architecture promotes the selected secondary option to be the primary option. The Design
Options dialog lists the design option with (primary) after its name. The former primary option
is now a secondary option.
NOTE If you encounter the error message Elements in main model will be deleted, see
Issues with Design Options
references and tags to be sure they are referencing the correct elements.
Referencing Elements in Design Options
See Design Options Toolbar
See Determining the Active Option
Revit Architecture lists the design options for the selected set.
If you clear a check box, the elements are not added to the corresponding design option.
Design Options, or click
on page 1260 for instructions.
on page 1240.
on page 1245.
(Add to Design Option Set).
on the Design Options
on page 1255.)
Troubleshooting
