5 Click OK.

Combining Phases

When you combine phases, the selected phase is deleted. All elements with that phase value for their Phase
Created and Phase Demolished properties update to show the new combined phase value.
To combine phases
1 Click Settings menu
2 Click the number box adjacent to the phase to combine with another phase.
3 Under Combine With, click Next or Previous.
4 Click OK.

Phase Filters

A phase filter is a rule that you apply to a view to control the display of elements based on their phase status:
new, existing, demolished, or temporary.
Default Phase Filters
Each Revit Architecture project contains the following default phase filters:
Show All: Shows new elements (using the graphics settings defined for that category of elements) and
existing, demolished, and temporary elements (using the Graphic Overrides settings for each phase
defined using Settings menu
Show Demo + New: Shows demolished elements and all new elements added to the building model.
Show New: Shows all new elements added to the building model.
Show Previous + Demo: Shows existing elements and demolished elements.
Show Previous + New: Shows all original elements that were not demolished (Show Previous) and all
new elements added to the building model (+ New).
Show Previous Phase: Shows all elements from the previous phase. In the first phase of a project, existing
elements are new to that phase, so applying the Show Previous Phase filter causes no elements to be
displayed.
NOTE To show all elements from all phases, do not apply a phase filter to the view.
Phase Status
Each view can show one or more phases of the construction. You can specify different graphic overrides for
each phase status.
New: Element was created in the phase of the current view.
Existing: Element was created in an earlier phase and continues to exist in the current phase.
Demolished: Element was created in an earlier phase and demolished in the current phase.
Temporary: Element was created and demolished during the current phase.
Phases.
Phases).
Combining Phases | 1265
