2 In the Import IFC Options dialog, click Load.
3 In the Open dialog, navigate to an IFC class mapping file, select it, and click Open.
4 In the Import IFC Options dialog, click OK.

Overriding Categories and Subcategories for Imported IFC Objects

1 Click File menu
2 In the Import IFC Options dialog, double-click in a category or subcategory and enter a new
3 Click OK, or to save the mappings in a new file, click Save As.

Linking AutoCAD Files to a Revit Project

You can link AutoCAD files to a Revit project. For example, you may want to use linked files as follows:
Some team members use AutoCAD to create details or elevations, but the rest of the project is created
using Revit Architecture. You want to link the AutoCAD drawings to the Revit project and place them
on sheets. Then, these drawings can be included in the set of construction documents that Revit
Architecture generates.
Team members from other disciplines (such as structural engineers or electrical engineers) are using
AutoCAD to plan their part of the project. You want to link their AutoCAD drawings to a Revit project
to use them as underlays for your project views.
For example, the following floor plan shows a linked file that will be used as an underlay to trace and create
structural walls in Revit Architecture.
Related topics
Managing Links
Managing Layers in Linked and Imported Files
1318 | Chapter 22 Interoperability
Import/Export Settings
value to override the current value.
As an alternative, you can click Standard to reset all values to the standard (default) settings.
on page 1222
IFC Options Import Options.
on page 1323
