2 In the Instance Properties dialog, edit beam system instance parameters.
3 Click Edit Type and edit beam system type parameters.
Beam System Type Properties
Name
Identity Data
Keynote
Model
Manufacturer
Type Comments
URL
Description
Assembly description
Type Mark
Cost
Keynote
Beam System Instance Properties
Name
Constraints
3D
Elevation
892 | Chapter 14 Structural Modeling
NOTE Changes made to type parameters affect all beam systems of this type in the project. You can
click Duplicate to create a new beam system type.
Description
Creates a non-planar beam system in which the elevation of a beam is defined by
its sketch lines. See
The vertical offset of beam system beams from the beam system work plane.
Description
The beam keynote. Add or edit the value. Click in the value
box to open the Keynotes dialog. See
The manufacturer internal number.
The shape manufacturer.
A field for entering general comments about the shape type.
This information can be included in a schedule.
A link to a web page that may contain type-specific informa-
tion.
Description of the beam. Enter a description.
Description of the assembly based on the assembly code se-
lection. This is a read-only value.
A value that designates the particular beam; possibly the shop
mark. This value must be unique for each element in a project.
Revit Architecture warns you if the number is already used
but allows you to continue using it. You can see the warning
using the Review Warnings tool. See
Messages
on page 1415.
The pricing of the beam.
The beam keynote. Add or edit the value. Click in the value
box to open the Keynotes dialog. See
Creating a 3D Beam System
on page 886.
Keynotes
on page 1117.
Reviewing Warning
Keynotes
on page 1117.
