Low-power timer (LPTIM) applied to STM32L4P5xx and STM32L4Q5xx only
42.7.5
LPTIM control register (LPTIM_CR)
Address offset: 0x010
Reset value: 0x0000 0000
31
30
29
Res.
Res.
Res.
Res.
15
14
13
Res.
Res.
Res.
Res.
Bits 31:5 Reserved, must be kept at reset value.
Bit 4 RSTARE: Reset after read enable
This bit is set and cleared by software. When RSTARE is set to '1', any read access to LPTIM_CNT
register asynchronously resets LPTIM_CNT register content.
Bit 3 COUNTRST: Counter reset
This bit is set by software and cleared by hardware. When set to '1' this bit triggers a synchronous
reset of the LPTIM_CNT counter register. Due to the synchronous nature of this reset, it only takes
place after a synchronization delay of 3 LPTimer core clock cycles (LPTimer core clock may be
different from APB clock).
Caution: COUNTRST must never be set to '1' by software before it is already cleared to '0' by
Bit 2 CNTSTRT: Timer start in Continuous mode
This bit is set by software and cleared by hardware.
In case of software start (TRIGEN[1:0] = '00'), setting this bit starts the LPTIM in Continuous mode.
If the software start is disabled (TRIGEN[1:0] different than '00'), setting this bit starts the timer in
Continuous mode as soon as an external trigger is detected.
If this bit is set when a single pulse mode counting is ongoing, then the timer does not stop at the
next match between the LPTIM_ARR and LPTIM_CNT registers and the LPTIM counter keeps
counting in Continuous mode.
This bit can be set only when the LPTIM is enabled. It is automatically reset by hardware.
Bit 1 SNGSTRT: LPTIM start in Single mode
This bit is set by software and cleared by hardware.
In case of software start (TRIGEN[1:0] = '00'), setting this bit starts the LPTIM in single pulse mode.
If the software start is disabled (TRIGEN[1:0] different than '00'), setting this bit starts the LPTIM in
single pulse mode as soon as an external trigger is detected.
If this bit is set when the LPTIM is in continuous counting mode, then the LPTIM stops at the
following match between LPTIM_ARR and LPTIM_CNT registers.
This bit can only be set when the LPTIM is enabled. It is automatically reset by hardware.
Bit 0 ENABLE: LPTIM enable
The ENABLE bit is set and cleared by software.
0: LPTIM is disabled.
1: LPTIM is enabled
1524/2301
28
27
26
25
Res.
Res.
Res.
12
11
10
9
Res.
Res.
Res.
hardware. Software should consequently check that COUNTRST bit is already cleared to '0'
before attempting to set it to '1'.
24
23
22
Res.
Res.
Res.
8
7
6
Res.
Res.
Res.
RM0432 Rev 6
21
20
19
18
Res.
Res.
Res.
Res.
5
4
3
2
RST
COUN
CNT
Res.
ARE
TRST
STRT
rw
rs
rw
RM0432
17
16
Res.
Res.
1
0
SNG
ENA
STRT
BLE
rw
rw
