Tamper and backup registers (TAMP) applied to STM32L4P5xx and STM32L4Q5xx only

Bits 31:8 Reserved, must be kept at reset value.

Bit 7 TAMPPUDIS: TAMP_INx pull-up disable

Bits 6:5 TAMPPRCH[1:0]: TAMP_INx precharge duration

Bits 4:3 TAMPFLT[1:0]: TAMP_INx filter count

Bits 2:0 TAMPFREQ[2:0]: Tamper sampling frequency

This register concerns only the tamper inputs in passive mode.

TAMP interrupt enable register (TAMP_IER)

Address offset: 0x2C

Backup domain reset value: 0x0000 0000

System reset: not affected

This bit determines if each of the TAMPx pins are precharged before each sample.

0: Precharge TAMP_INx pins before sampling (enable internal pull-up)

1: Disable precharge of TAMP_INx pins.

These bit determines the duration of time during which the pull-up/is activated before each

sample. TAMPPRCH is valid for each of the TAMP_INx inputs.

0x0: 1 RTCCLK cycle

0x1: 2 RTCCLK cycles

0x2: 4 RTCCLK cycles

0x3: 8 RTCCLK cycles

These bits determines the number of consecutive samples at the specified level

(TAMP*TRG) needed to activate a tamper event. TAMPFLT is valid for each of the

TAMP_INx inputs.

0x0: Tamper event is activated on edge of TAMP_INx input transitions to the active level (no

internal pull-up on TAMP_INx input).

0x1: Tamper event is activated after 2 consecutive samples at the active level.

0x2: Tamper event is activated after 4 consecutive samples at the active level.

0x3: Tamper event is activated after 8 consecutive samples at the active level.

Determines the frequency at which each of the TAMP_INx inputs are sampled.

0x0: RTCCLK / 32768 (1 Hz when RTCCLK = 32768 Hz)

0x1: RTCCLK / 16384 (2 Hz when RTCCLK = 32768 Hz)

0x2: RTCCLK / 8192 (4 Hz when RTCCLK = 32768 Hz)

0x3: RTCCLK / 4096 (8 Hz when RTCCLK = 32768 Hz)

0x4: RTCCLK / 2048 (16 Hz when RTCCLK = 32768 Hz)

0x5: RTCCLK / 1024 (32 Hz when RTCCLK = 32768 Hz)

0x6: RTCCLK / 512 (64 Hz when RTCCLK = 32768 Hz)

0x7: RTCCLK / 256 (128 Hz when RTCCLK = 32768 Hz)

RM0432 Rev 6
