ST STM32L4+ Series Reference Manual page 1570

Real-time clock (RTC) applied to STM32L4Rxxx and STM32L4Sxxx only
46.6.4 RTC initialization and status register (RTC_ISR)
This register is write protected (except for RTC_ISR[13:8] bits). The write access procedure
is described in
Address offset: 0x0C
Backup domain reset value: 0x0000 0007
System reset: not affected except INIT, INITF, and RSF bits which are cleared to '0'
31 30 29
Res. Res. Res.
15 14 13
TAMP3F TAMP2F TAMP1F TSOVF
rc_w0 rc_w0 rc_w0
Bits 31:18 Reserved, must be kept at reset value.
Bit 17 ITSF: Internal tTime-stamp flag
This flag is set by hardware when a time-stamp on the internal event occurs.
This flag is cleared by software by writing 0, and must be cleared together with TSF bit by
writing 0 in both bits.
Bit 16 RECALPF: Recalibration pending Flag
The RECALPF status flag is automatically set to '1' when software writes to the RTC_CALR
register, indicating that the RTC_CALR register is blocked. When the new calibration settings
are taken into account, this bit returns to '0'. Refer to
Bit 15 TAMP3F: RTC_TAMP3 detection flag
This flag is set by hardware when a tamper detection event is detected on the RTC_TAMP3
input.
It is cleared by software writing 0
Bit 14 TAMP2F: RTC_TAMP2 detection flag
This flag is set by hardware when a tamper detection event is detected on the RTC_TAMP2
input.
It is cleared by software writing 0
Bit 13 TAMP1F: RTC_TAMP1 detection flag
This flag is set by hardware when a tamper detection event is detected on the RTC_TAMP1
input.
It is cleared by software writing 0
Bit 12 TSOVF: Time-stamp overflow flag
This flag is set by hardware when a time-stamp event occurs while TSF is already set.
This flag is cleared by software by writing 0. It is recommended to check and then clear
TSOVF only after clearing the TSF bit. Otherwise, an overflow might not be noticed if a time-
stamp event occurs immediately before the TSF bit is cleared.
Bit 11 TSF: Time-stamp flag
This flag is set by hardware when a time-stamp event occurs.
This flag is cleared by software by writing 0. If ITSF flag is set, TSF must be cleared together
with ITSF by writing 0 in both bits.
1570/2301
RTC register write protection on page
28 27 26 25
Res. Res. Res. Res.
12 11 10 9
TSF WUTF ALRBF ALRAF
rc_w0 rc_w0 rc_w0 rc_w0
1553.
24 23 22
Res. Res. Res. Res.
8 7 6
INIT INITF RSF
rc_w0 rw r rc_w0
RM0432 Rev 6
21 20 19 18
Res. Res. Res.
5 4 3 2
INITS SHPF WUTWF
r r r
Re-calibration on-the-fly.
RM0432
17 16
ITSF RECALPF
rc_w0 r
1 0
ALRB
ALRAWF
WF
r r
