Main menu provides access to all parameters.
Quick menu takes the user through a few parameters, making it possible to start operating the drive. Change a parameter in either
main menu mode or quick menu mode.

4.1.5 Quick Menu Key Functions

Press [Quick Menu] to enter a list of different areas contained in the Quick Menu.
0RPM 0.00A
Quick Menus
Q1 My Personal Menu
Q2 Quick Setup
Q4 Smart Setup
Q5 Changes Made
Illustration 13: Quick Menus
Select Q1 My Personal Menu to show the selected personal parameters. These parameters are selected in parameter 0-25 My Personal
Menu. Up to 50 different parameters can be added in this menu.
Select Q2 Quick Setup to go through a selection of parameters to get the motor running almost optimally. The default settings for
the other parameters consider the required control functions and the configuration of signal inputs/outputs (control terminals).
The parameter selection is effected with the navigation keys. The parameters in the following table are accessible.
Table 2: Selection of Parameter
Parameter
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
Parameter 5-12 Terminal 27 Digital Input
Parameter 1-29 Automatic Motor Adaptation (AMA)
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-41 Ramp 1 Ramp Up Time
Parameter 3-42 Ramp 1 Ramp Down Time
Parameter 3-13 Reference Site
If terminal 27 is set to [0] No operation, no connection to +24 V on terminal 27 is necessary.
1
Select Changes made to get information about:
• The last 10 changes. Use the [▵] [▿] navigation keys to scroll between the last 10 changed parameters.
• The changes made since default setting.
Select Loggings to get information about the shown line readouts. The information is shown as graphs. Only parameters selected in
parameter 0-20 Display Line 1.1 Small and parameter 0-24 Display Line 3 Large can be viewed. It is possible to store up to 120 samples
in the memory for later reference.
Danfoss A/S © 2022.12
1(1)
Setting
Select the language. Default is [0] English.
[kW]
[V]
[Hz]
[A]
[RPM]
[0] No function
[1] Enable complete AMA
[RPM]
[RPM]
[s]
[s]
Select whether to control the drive via digital inputs, LCP, or remote control.
(1)
AU275636650261en-000101 / 130R0334 | 25
