Danfoss VLT AutomationDrive FC 301 Programming Manual page 53

VLT AutomationDrive FC 301/302
Programming Guide
Parameter 0-33 Source for User-defined Readout
Table 24: Parameter 0-33 Source of User-defined Readout
0-33 Source of User-defined Readout
Default value: [240] Default Source
Conversion index: –
Enter the source of the user-defined readout.
Option Name
[105] Torque related to rated
[143] PID Clamped Output 4–20mA
[240]* Default Source
Parameter 0-37 Display Text 1
Table 25: Parameter 0-37 Display Text 1
0-37 Display Text 1
Default value: 0
Conversion index: 0
Enter a text which can be viewed in the graphical display by selecting [37] Display Text 1 in
•
Parameter 0-20 Display Line 1 Small
• Parameter 0-21 Display Line 1.2 Small
• Parameter 0-22 Display Line 1.3 Small
•
Parameter 0-23 Display Line 2 Large
• Parameter 0-24 Display Line 3 Large
Parameter 0-38 Display Text 2
Table 26: Parameter 0-38 Display Text 2
0-38 Display Text 2
Default value: 0
Conversion index: 0
Enter a text which can be viewed in the graphical display by selecting [38] Display Text 2 in
•
Parameter 0-20 Display Line 1 Small
• Parameter 0-21 Display Line 1.2 Small
•
Parameter 0-22 Display Line 1.3 Small
•
Parameter 0-23 Display Line 2 Large
• Parameter 0-24 Display Line 3 Large
Parameter 0-39 Display Text 3
Table 27: Parameter 0-39 Display Text 3
0-39 Display Text 3
Default value: 0
Conversion index: 0
Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Parameter type: Range, 0–25
Data type: VisStr[25]
Parameter type: Range, 0–25
Data type: VisStr[25]
Parameter type: Range, 0–25
Data type: VisStr[25]
Parameter Descriptions
Setup: All setups
Change during operation: True
Description
Setup: 1 setup
Change during operation: True
Setup: 1 setup
Change during operation: True
Setup: 1 setup
Change during operation: True
AU275636650261en-000101 / 130R0334 | 53
