Danfoss VLT AutomationDrive FC 301 Programming Manual page 375

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[28] Logic rule 2
[29] Logic rule 3
[33] Digital input DI18
[34] Digital input DI19
[35] Digital input DI27
[36] Digital input DI29
[37] Digital input DI32
[38] Digital input DI33
[39] Start command
[40] Drive stopped
[41] Reset trip
[42] Auto-reset trip
[43] OK key
[44] Reset key
[45] Left key
[46] Right key
[47] Up key
[48] Down key
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[76] Digital input X30/2
[77] Digital input X30/3
[78] Digital input X30/4
[79] Digital input X46/1
[80] Digital input X46/3
[81] Digital input X46/5
[82] Digital input X46/7
[83] Digital input X46/9
Danfoss A/S © 2022.12
Description
Use the result of logic rule 2.
Use the result of logic rule 3.
Use the result of digital input 18.
Use the result of digital input 19.
Use the result of digital input 27.
This option is only available in FC 302.
Use the result of digital input 29.
Use the result of digital input 32.
Use the result of digital input 33.
A start command is issued. This is the default option.
A stop command (jog, stop, quick stop, coast) is issued - and not from SLC itself.
A reset is issued.
An auto reset is performed.
[OK] is pressed. Only available on the graphical LCP.
[Reset] is pressed. Only available on the graphical LCP.
[◃] is pressed. Only available on the graphical LCP.
[▹] is pressed. Only available on the graphical LCP.
[▵] is pressed. Only available on the graphical LCP.
[▿] is pressed. Only available on the graphical LCP.
Use the result of comparator 4.
Use the result of comparator 5.
Use the result of logic rule 4.
Use the result of logic rule 5.
Use the value of X30/2 (VLT® General Purpose I/O MCB 101).
Use the value of X30/3 (VLT® General Purpose I/O MCB 101).
Use the value of X30/4 (VLT® General Purpose I/O MCB 101).
Use the value of X46/1 (VLT® Extended Relay Card MCB 113).
Use the value of X46/3 (VLT® Extended Relay Card MCB 113).
Use the value of X46/5 (VLT® Extended Relay Card MCB 113).
Use the value of X46/7 (VLT® Extended Relay Card MCB 113).
Use the value of X46/9 (VLT® Extended Relay Card MCB 113).
N O T I C E
AU275636650261en-000101 / 130R0334 | 375
Parameter Descriptions
