VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[4] Position error
[5] Position limit
[6] Touch on target
[7] Touch activated
[8] Touch sensor found
[9] Vir. master on ref
[10] T18DI status
[11] T19DI status
[12] T27DI status
[13] T29DI status
[14] T32DI status
[15] T33DI status
[16] T37DI status
[17] X30/2 DI status
[18] X30/3 DI status
276 | Danfoss A/S © 2022.12
Description
This option is only available with software version 48.XX.
The position is outside its limits set in parameter 3-06 Minimum Position and parameter
3-07 Maximum Position.
This option is only available with software version 48.XX.
The position error exceeds the value in parameter 4-71 Maximum Position for the time
set in parameter 4-72 Position Error Timeout.
This option is only available with software version 48.XX.
Target position is reached in touch probe position mode.
This option is only available with software version 48.XX.
Touch probe positioning is active. The drive monitors the touch probe sensor input.
This option is only available with software version 48.XX.
The touch sensor has been detected.
This option is only available with software version 48.XX.
The virtual master is running on the set reference.
The input goes high whenever T37 has 0 V and goes low whenever T37 has 24 V.
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334
Parameter Descriptions
