Danfoss VLT AutomationDrive FC 301 Programming Manual page 417

VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[222] Homing OK
[223] On target
[224] Position error
[225] Position limit
[226] Touch on target
[227] Touch activated
[228] Comparator 6
[229] Comparator 7
[230] Comparator 8
[231] Comparator 9
[232] Logic rule 6
[233] Logic rule 7
[234] Logic rule 8
[235] Logic rule 9
[236] SL time-out 8
[237] SL time-out 9
Danfoss A/S © 2022.12
Description
This option is only available with software version 48.2X or newer.
Homing is completed with the selected homing function (parameter 17-80 Homing Function).
This option is only available with software version 48.2X or newer.
Positioning is completed and the on target signal is sent when the actual position is within
parameter 3-05 On Reference Window for the duration of parameter 3-09 On Target Time and
the actual speed does not exceed parameter 3-05 On Reference Window.
This option is only available with software version 48.2X or newer.
The position error exceeds the value in parameter 4-71 Maximum Position Error for the time
set in parameter 4-72 Position Error Timeout.
This option is only available with software version 48.2X or newer.
The position is outside the limits set in parameter 3-06 Minimum Position and parameter 3-07
Maximum Position.
This option is only available with software version 48.2X or newer.
Target position is reached in touch probe position mode.
Touch probe positioning is active. The drive monitors the touch probe sensor input.
N O T I C E
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334 | 417
Parameter Descriptions
