VLT AutomationDrive FC 301/302
Programming Guide
Parameter 36-14 Terminal X49/1 Low Ref./Feedb. Value
Table 1313: Parameter 36-14 Terminal X49/1 Low Ref./Feedb. Value
36-14 Terminal X49/1 Low Ref./Feedb. Value
Default value: 0 ReferenceFeedbackUnit
Conversion index: 0
Parameter 36-15 Terminal X49/1 High Ref./Feedb. Value
Table 1314: Parameter 36-15 Terminal X49/1 High Ref./Feedb. Value
36-15 Terminal X49/1 High Ref./Feedb. Value
Default value: 100 ReferenceFeedbackU-
nit
Conversion index: 0
Parameter 36-16 Term. X49/1 Filter Time Constant
Table 1315: Parameter 36-16 Term. X49/1 Filter Time Constant
36-16 Term. X49/1 Filter Time Constant
Default value: 0.001 s
Conversion index: 0
Enter the filter time constant. This is a first-order digital low-pass filter time constant for suppressing electrical noise in terminal
X49/1. A high time constant value improves dampening but also increases the time delay through the filter.
5.29.3 36-2* Analog Input X49/3
This parameter group is only available in FC 302.
Parameter 36-20 Terminal X49/3 Low Voltage
Table 1316: Parameter 36-20 Terminal X49/3 Low Voltage
36-20 Terminal X49/3 Low Voltage
Default value: 0.07 V
Conversion index: 0
Parameter 36-21 Terminal X49/3 Low Current
Table 1317: Parameter 36-21 Terminal X49/3 Low Current
36-21 Terminal X49/3 Low Current
Default value: 4 mA
Conversion index: -3
640 | Danfoss A/S © 2022.12
Parameter type: Range, -999999.999 - 999999.999
ReferenceFeedbackUnit
Data type: Int32
Parameter type: Range, -999999.999 - 999999.999
ReferenceFeedbackUnit
Data type: Int32
Parameter type: Range, 0.001 - 10 s
Data type: Uint16
N O T I C E
Parameter type: Range, 0 - 10 V
Data type: Int16
Parameter type: Range, 0 - 20 mA
Data type: Int16
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
