VLT AutomationDrive FC 301/302
Programming Guide
21/71 in this parameter are available. Instances 100/150 and 101/151 are Danfoss specific. Instances 20/70 and 21/71 are ODVA-
specific AC motor profiles. For guidelines in telegram selection, refer to the VLT® DeciveNet MCA 104 Installation Guide.
A change to this parameter is executed immediately.
Option
[0]
[1]
[2]
[3]
[6]
Parameter 10-11 Process Data Config Write
Table 586: Parameter 10-11 Process Data Config Write
10-11 Process Data Config Write
Default value: Size related
Conversion index: –
Option Name
[-] None
[109] Mode of operation
[302] Minimum reference
[303] Maximum reference
[312] Catch up/slow down value
[321] Touch target
[322] Master scale numerator
[323] Master scale denominator
[326] Master Offset
[328] Master offset speed ref
[341] Ramp 1 ramp up time
[342] Ramp 1 ramp down time
[351] Ramp 2 ramp up time
[352] Ramp 2 ramp down time
[361] Ramp 3 ramp up time
[362] Ramp 3 ramp down time
[380] Jog/homing ramp time jog ramp time
Danfoss A/S © 2022.12
N O T I C E
Name
Instance 100/150
Instance 101/151
Instance 20/70
Instance 21/71
Instance 102/152
Parameter type: Option
Data type: Uint16
Parameter Descriptions
Description
Setup: All setups
Change during operation: True
Description
