VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[91] Torque limit & stop
[92] Brake fault (IGBT)
[93] Mech. brake control
[94] Safe stop active
[100] Comparator 0
[101] Comparator 1
[102] Comparator 2
[103] Comparator 3
[104] Comparator 4
[105] Comparator 5
[106] Comparator 6
[107] Comparator 7
[108] Comparator 8
[109] Comparator 9
[110] Logic rule 0
[111] Logic rule 1
[112] Logic rule 2
[113] Logic rule 3
[114] Logic rule 4
[115] Logic rule 5
[116] Logic rule 6
[117] Logic rule 7
[118] Logic rule 8
[119] Logic rule 9
[120] SL time-out 0
[121] SL time-out 1
[122] SL time-out 2
[123] SL time-out 3
[124] SL time-out 4
[125] SL time-out 5
384 | Danfoss A/S © 2022.12
Description
If the drive has received a stop signal and is at the torque limit, the signal is logic 0.
The brake IGBT is short-circuited.
The mechanical brake is active.
This option is only available in FC 302.
The result of comparator 0.
The result of comparator 1.
The result of comparator 2.
The result of comparator 3.
The result of comparator 4.
The result of comparator 5.
The result of comparator 6.
The result of comparator 7.
The result of comparator 8.
The result of comparator 9.
The result of logic rule 0.
The result of logic rule 1.
The result of logic rule 2.
The result of logic rule 3.
The result of logic rule 4.
The result of logic rule 5.
The result of logic rule 6.
The result of logic rule 7.
The result of logic rule 8.
The result of logic rule 9.
The result of the SLC timer 0.
The result of the SLC timer 1.
The result of the SLC timer 2.
The result of the SLC timer 3.
The result of the SLC timer 4.
The result of the SLC timer 5.
N O T I C E
AU275636650261en-000101 / 130R0334
Parameter Descriptions
