VLT AutomationDrive FC 301/302
Programming Guide
Option
Name
[4]
ETR trip 1
[5]
ETR warning 2
[6]
ETR trip 2
[7]
ETR warning 3
[8]
ETR trip 3
[9]
ETR warning 4
[10]
ETR trip 4
[20]
ATEX ETR
[21]
Advanced ETR
If [20] ATEX ETR is selected, follow the instructions in the dedicated chapter of the design guide and the instructions provided by
the motor manufacturer.
If [20] ATEX ETR is selected, set parameter 4-18 Current Limit to 150%.
Parameter 1-91 Motor External Fan
Table 137: Parameter 1-91 Motor External Fan
1-91 Motor External Fan
Default value: Size related
Conversion index: –
Option
Name
Description
[0]
No
No external fan is required, that is the motor is derated at low speed.
[1]
Yes
Applies an external motor fan (external ventilation), so no derating of the motor is required at low speed. The
upper curve in
rent (see parameter 1-24 Motor Current). If the motor current exceeds nominal current, the operation time still
decreases as if no fan was installed.
Parameter 1-93 Thermistor Resource
Table 138: Parameter 1-93 Thermistor Resource
1-93 Thermistor Resource
Default value: [0] None
Conversion index: –
Danfoss A/S © 2022.12
Description
Calculates the load when set-up 1 is active and stops (trips) the drive when the motor is overloa-
ded. Program a warning signal via 1 of the digital outputs. The signal appears in the event of a
warning and if the drive trips (thermal warning).
Activates the thermal monitoring function for Ex-e motors for ATEX. Enables parameter 1-94 ATEX
ETR cur.lim. speed reduction, parameter 1-98 ATEX ETR interpol. points freq., and parameter 1-99
ATEX ETR interpol points current.
N O T I C E
N O T I C E
Parameter type: Option
Data type: Uint8
Illustration 43
(f
= 1 x f
out
M,N
Parameter type: Option
Data type: Uint8
Setup: All setups
Change during operation: True
) is followed if the motor current is lower than nominal motor cur-
Setup: All setups
Change during operation: True
Parameter Descriptions
AU275636650261en-000101 / 130R0334 | 103
