Danfoss VLT AutomationDrive FC 301 Programming Manual page 577

VLT AutomationDrive FC 301/302
Programming Guide
Parameter 30-02 Wobble Delta Freqeuncy [%]
Table 1065: Parameter 30-02 Wobble Delta Freqeuncy [%]
30-02 Wobble Delta Freqeuncy [%]
Default value: 25%
Conversion index: 0
The delta frequency can also be expressed as a percentage of the center frequency and can thus be maximum 100%. The function is
the same as for parameter 30-01 Wobble Delta Frequency [Hz].
Parameter 30-03 Wobble Delta Freq. Scaling Resource
Table 1066: Parameter 30-03 Wobble Delta Freq. Scaling Resource
30-03 Wobble Delta Freq. Scaling Resource
Default value: [0] No function
Conversion index: -
Select the drive input to be used for scaling the delta frequency setting.
Option Name
[0]* No function
[1] Analog input 53
[2] Analog input 54
[3] Frequency input 29
[4] Frequency input 33
[7] Analog input X30/11
[8] Analog input X30/12
[15] Analog input X48/2
[16] Analog input X49/1
[17] Analog input X49/3
[18] Analog input X49/5
Parameter 30-04 Wobble Jump Frequency [Hz]
Table 1067: Parameter 30-04 Wobble Jump Frequency [Hz]
30-04 Wobble Jump Frequency [Hz]
Default value: 0 Hz
Conversion index: -1
The jump frequency is used to compensate for the inertia in the traverse system. If a jump in the output frequency is required at the
boundaries of the wobble sequence, the frequency jump is set in this parameter. If the traverse system has a very high inertia, a high
jump frequency may create a torque limit warning or trip or an overvoltage warning or trip. This parameter can only be changed in
stop mode.
Danfoss A/S © 2022.12
Parameter type: Range, 0 - 100%
Data type: Uint8
Parameter type: Option
Data type: Uint8
Description
This option is only available in FC 302.
Parameter type: Range, 0 - 20.0 Hz
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
Setup: All setups
Change during operation: True
N O T I C E
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334 | 577
