Danfoss VLT AutomationDrive FC 301 Programming Manual page 188

VLT AutomationDrive FC 301/302
Programming Guide
Option Function
[128] Dir. home sen.
inv.
Normally closed contact for defining the home position at the same edge of the sensor signal inde-
pendent of running direction. Only for the 2 homing types [2] Home Sync and [9] Direction with Sensor.
[190] Emcy mode ref Enables a choice between 1 of the 8 preset reference according to
bit 0
[191] Emcy mode ref Enables a choice between 1 of the 8 preset reference according to
bit 1
[192] Emcy mode ref Enables a choice between 1 of the 8 preset reference according to
bit 2
[193] Emcy mode Switch between emergency mode setup 1 to 4 in parameter group 24-0* Emergency Mode and parame-
setup bit 0
ter group 24-4* Emergency Mode 2 without changing starting setup mode for the rest of the parameters.
[194] Emcy mode Switch between emergency mode setup 1 to 4 in parameter group 24-0* Emergency Mode and parame-
setup bit 1
ter group 24-4* Emergency Mode 2 without changing starting setup mode for the rest of the parameters.
[195] Test emcy Activation of emergency mode via parameter 24-09 Emergency Mode Alarm Handling, option [2] Trip all
mode
alarms/test with stop on all alarms and in normal operation mode. The test timer is set in parameter
24-42 Timeout for Emergency Mode Test, and countdown starts when the test signal is active.
[196] Reset emcy
When operating in emergency mode with impulse signals (parameter 24-43 Emergency Mode Signal Op-
mode
eration, option [2] Impulse, set-reset) the reset signal stops the emergency mode operation.
[231] Power limit
mot.
Serves as input to activate the power limit function in the motor mode. See parameter group 4-8* Power
Limit.
[232] Power limit
gen.
Serves as input to activate the power limit function in the generating mode. See parameter group 4-8*
Power Limit.
[233] Power limit
both
Serves as input to activate the power limit function in both the motor and the generating mode. See
parameter group 4-8* Power Limit.
[234] Light load +
evacuation
Use this option to activate both light-load detection and evacuation.
188 | Danfoss A/S © 2022.12
This option is only available with software version 48.XX.
This option is only available in FC 302.
This option is only available in FC 302.
This option is only available in FC 302.
This option is only available in FC 302.
N O T I C E
Table
Table
Table
N O T I C E
N O T I C E
N O T I C E
N O T I C E
AU275636650261en-000101 / 130R0334
Parameter Descriptions
329.
329.
329.
