VLT AutomationDrive FC 301/302
Programming Guide
Option
Name
[1624]
Calibrated stator resistance
[1625]
Torque [Nm] high
[1628]
Angle error
[1630]
DC link voltage
[1632]
Brake energy /s
[1633]
Brake energy average
[1634]
Heatsink temp.
[1635]
Inverter thermal
[1638]
SL controller state
[1639]
Control card temp.
[1642]
Service log counter
[1644]
Speed error [RPM]
[1645]
Motor phase U current
[1646]
Motor phase V current
[1647]
Motor phase W current
[1648]
Speed ref. after ramp [RPM]
[1650]
External reference
[1651]
Pulse reference
[1652]
Feedback[Unit]
[1653]
Digi pot reference
[1657]
Feedback [RPM]
[1660]
Digital input
[1661]
Terminal 53 switch setting
[1662]
Analog input 53
[1663]
Terminal 54 switch setting
[1664]
Analog input 54
[1665]
Analog output 42 [mA]
[1666]
Digital output [bin]
[1667]
Freq. input #29 [Hz]
[1668]
Freq. input #33 [Hz]
[1669]
Pulse output #27 [Hz]
[1670]
Pulse output #29 [Hz]
356 | Danfoss A/S © 2022.12
Parameter Descriptions
Description
AU275636650261en-000101 / 130R0334
