VLT AutomationDrive FC 301/302
Programming Guide
Option
[1]*
[2]
[3]
[4]
Parameter 32-11 User Unit Denominator
Table 1122: Parameter 32-11 User Unit Denominator
32-11 User Unit Denominator
Default value: 1
Conversion index: 0
All target positions are made in user units and are converted to quad-counts internally. By selecting scaling units, it is possible to
work with any measurement unit (for example mm). This factor consists of a numerator and denominator.
Parameter 32-12 User Units Numerator
Table 1123: Parameter 32-12 User Units Numerator
32-12 User Units Numerator
Default value: 1
Conversion index: 0
All target positions are made in user units and are converted to quad-counts internally. By selecting scaling units, it is possible to
work with any measurement unit (for example mm). This factor consists of a numerator and denominator.
Parameter 32-13 Enc.2 Control
Table 1124: Parameter 32-13 Enc.2 Control
32-13 Enc.2 Control
Default value: [0] No soft changing
Conversion Index: -
Enables bump-less changing of feedback encoder in software while running and setting position to 0 without loosing the actual
position.
Option Name
[0]* No soft changing
[1] Encoder soft changing enable
[2] Soft zero setting enable
[3] Encoder soft changing and soft zero enable
Parameter 32-14 Enc.2 Node ID
Table 1125: Parameter 32-14 Enc.2 Node ID
32-14 Enc.2 Node ID
Default value: 127
Conversion index: 0
Danfoss A/S © 2022.12
Name
No action
Reference reversed
User units reserved
Uu and ref reversed
Parameter type: Range, 1 - 1073741823
Data type: Uint32
Parameter type: Range, 1 - 1073741823
Data type: Uint32
Parameter type: Option
Data Type: Uint8
Parameter type: Range, 1 - 127
Data type: Uint8
Parameter Descriptions
Description
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
AU275636650261en-000101 / 130R0334 | 591
