VLT AutomationDrive FC 301/302
Programming Guide
Parameter 36-03 Term. X49/7 Mode
Table 1306: Parameter 36-03 Term. X49/7 Mode
36-03 Term. X49/7 Mode
Default value: [0] Voltage 0–10V
Conversion index: -
Select the output mode of analog terminal X49/7.
Option Name
[0]* Voltage 0–10V
[1] Voltage 2–10V
[2] Current 0–20mA
[3] Current 4–20mA
[4] Digital
Parameter 36-04 Term. X49/9 Mode
Table 1307: Parameter 36-04 Term. X49/9 Mode
36-04 Term. X49/9 Mode
Default value: [0] Voltage 0–10V
Conversion index: -
Select the output mode of analog terminal X49/9.
Option Name
[0]* Voltage 0–10V
[1] Voltage 2–10V
[2] Current 0–20mA
[3] Current 4–20mA
[4] Digital
Parameter 36-05 Term. X49/11 Mode
Table 1308: Parameter 36-05 Term. X49/11 Mode
36-05 Term. X49/11 Mode
Default value: [0] Voltage 0–10V
Conversion index: -
638 | Danfoss A/S © 2022.12
Parameter type: Option
Data type: Uint8
Description
This option is only available in FC 302.
Parameter type: Option
Data type: Uint8
Description
This option is only available in FC 302.
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
N O T I C E
Setup: All setups
Change during operation: True
N O T I C E
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
