VLT AutomationDrive FC 301/302
Programming Guide
Option Name
[197] RS Flipflop 5
[198] RS Flipflop 6
[199] RS Flipflop 7
[221] IGBT-cooling
[222] Homing OK
[223] On target
[224] Position limit
[225] Position error
[226] Touch on target
[227] Touch activated
[231] In power lim. mot.
[232] In power lim. gen.
[233] In power limit
[234] PE power off
[246] Emcy mode was act.
[247] Emergency mode
[249] Emcy m OPR unexpected
[250] Emcy mode limits
[254] Testing emcy mode
Parameter 36-52 Terminal X49/9 Min. Scale
Table 1338: Parameter 36-52 Terminal X49/9 Min. Scale
36-52 Terminal X49/9 Min. Scale
Default value: 0%
Conversion index: 0
Match the minimum output of terminal X49/9 with a required value. The required value is defined as a percentage of the value
selected in parameter 36-50 Terminal X49/9 Analogue Output. To know more about how this parameter works, see parameter 6-52
Terminal 42 Output Max Scale. The following example describes how the drive uses this parameter. Example:
•
Parameter 36-04 Terminal X49/9 Mode = [0] Voltage 0–10 V.
• Parameter 36-50 Terminal X49/9 Analogue Output = [100] Output frequency.
• Parameter 4-19 Max Output Frequency = 200 Hz.
Application requirement: If the output frequency is lower than 20 Hz, the output of terminal X49/9 should be 0 V. To fulfil the exam-
ple requirement, enter 10% in parameter 36-52 Terminal X49/9 Min. Scale.
654 | Danfoss A/S © 2022.12
Parameter type: Range, 0 - 200%
Data type: Int16
Parameter Descriptions
Description
Setup: All setups
Change during operation: True
AU275636650261en-000101 / 130R0334
