Parameter 32-38 Absolute Encoder Cable Length
Table 1134: Parameter 32-38 Absolute Encoder Cable Length
32-38 Absolute Encoder Cable Length
Default Value: 0
Conversion Index: 0
Set the total cable length (in meters) to avoid that the absolute encoder (SSI) signals come out of synchronization due to signal
delays caused by long encoder cables. VLT® Motion Control Option MCO 305 and VLT® Motion Control Option MCO 302 compen-
sate for the cable delay when the cable length is known.
Parameter 32-39 Encoder Monitoring
Table 1135: Parameter 32-39 Encoder Monitoring
32-39 Encoder Monitoring
Default value: [0] Off
Conversion index: -
Option
[0]*
[1]
[2]
[3]
[4]
Parameter 32-40 Encoder Termination
Table 1136: Parameter 32-40 Encoder Termination
32-40 Encoder Termination
Default value: [1] No action
Conversion index: -
Option
[1]*
[2]
[3]
[4]
Parameter 32-43 Enc.1 Control
Table 1137: Parameter 32-43 Enc.1 Control
32-43 Enc.1 Control
Default value: [0] No soft changing
Conversion index: -
594 | Danfoss A/S © 2022.12
Parameter Type: Range, 0 - 300 m
Data Type: Uint16
Parameter type: Option
Data type: Uint8
Name
Off
3 channels
2 channels
Warning
Alarm
Parameter type: Option
Data type: Uint8
Name
No action
Reference reversed
User units reserved
Uu and ref reversed
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: 2 setups
Change during operation: True
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
Description
Setup: 2 setups
Change during operation: True
AU275636650261en-000101 / 130R0334
