[246] Emcy mode was act.
[247] Emergency mode
[249] Emcy m. OPR unex-
pected
[250] Emcy mode limits
[254] Testing emcy mode
Parameter 5-30 Terminal 27 Digital Output
Table 356: Parameter 5-30 Terminal 27 Digital Output
5-30 Terminal 27 Digital Output
Default value: Size related
Conversion index: –
Select the function from the available digital output range and the additional options [60] Counter A (up), [61] Counter A (down), [63]
Counter B (up), and [64] Counter B (down). Counters are used in smart logic control functions. All functions are described in
and Table 355.
Option Name
[0] No operation
[1] Control ready
[2] Drive ready
[3] Coast and reset inv
[4] Enable/no warning
[5] Running
[6] Running/no warning
[7] Run in range/no warn
[8] Run on ref/no warn
[9] Alarm
[10] Alarm or warning
[11] At torque limit
[12] Out of current range
[13] Below current, low
[14] Above current, high
[15] Out of speed range
[16] Below speed, low
[17] Above speed, high
Danfoss A/S © 2022.12
Function
The drive has been operating in emergency mode.
The drive is operating in emergency mode. See parameter group 24-0* Emergency Mode.
Emergency mode input or safe stop is not operating as expected, for example, live zero monitor-
ing on an analog input is activated.
During emergency mode operation, 1 of the critical alarms has been activated and suppressed by
emergency mode. This may lead to reduced drive performance and expected operation lifetime
before service is required.
Emergency mode is activated in a special test mode where the drive stops on all alarms.
Parameter type: Option
Data type: Uint8
Parameter Descriptions
Setup: All setups
Change during operation: True
Description
AU275636650261en-000101 / 130R0334 | 205
Table 353
