VLT AutomationDrive FC 301/302
Programming Guide
Bit
0
13
Set-up select LSB
14
Set-up select MSB
15
No reversing
Different from [0] FC Profile. Options for bits 0–2, and 12–15 in parameter 8-14 Configurable Control Word CTW:
1
•
[11] Start Homing
•
[12] Activate Touch Probe
•
[13] Sync. to Pos. Mode
•
[14] Ramp 2
•
[15] Relay 1
•
[16] Relay 2
•
[17] Speed Mode
•
[18] Start Virtual Master
•
[19] Activate Master Offset
•
[21] Target Inverse
•
[26] Home Sensor
•
[27] Touch Sensor
•
[28] Position Vir. Master
•
[29] Set Master Home
•
[30] Set Vir. Mas. Pos. to Actual
•
[31] Activate CAM Table
Table 1433: Status Word
Bit
0
0
Control not ready
1
Drive not ready
2
Coasting
3
No error
4
Not homed
(1)
5
Reserved
6
No error
7
No warning
8
Not on target position
(1)
9
Local operation
10
Out of frequency limit
11
No operation
12
Drive OK
Danfoss A/S © 2022.12
Integrated Motion Controller
1
–
–
Reversing
1
Control ready
Drive ready
Enable
Trip
Home done
Reserved
Trip lock
Warning
Target position reached
Bus control
Frequency limit OK
In operation
Stopped, auto start
AU275636650261en-000101 / 130R0334 | 689
